HD 20x optical zoom conference camera
HD920-U30-K5
Quantity
HD 20x optical zoom is perfect for middle office or conference room
- Connect to Windows/Android/Linux devices without other software
- USB3.0 output video without compression and support USB2.0 meanwhile
- Autofocus makes everyone in the conference room clear and vivid
---------------------------------------------------------------------------------------
Product Description
- 1/2.8” Progressive CMOS, 2.1 megapixel
- USB 3.0 high speed transfer
- 20x optical zoom * 12x digital zoom
- Support YUY2 1080p30 and 720p30, 640*480 etc
- HOV: 58.7°- 3.2°
- VISCA, PELCO-D, UVC1.5 protocol
---------------------------------------------------------------------------------------
20x optical zoom * 12 digital zoom, 1080p resolution show the clear zoom in/out even the corner of the conference room. Vivid video quality can be shared synchronously.
Plug and play, easy to install with 12v power supply and USB 3.0 fast transfer. Control the camera by RS232C, RS485 etc.
Easy to set a live conferencing in any conference room within several minutes.
Compatible with Most Cloud Conferencing software
DIMENSIONS
Specs:
- 1/2.8” Progressive CMOS, 2.1 megapixel
- HOV: 58.7°- 3.2°
- 20 Optical X 12 Digital zoom
- USB 3.0
- f=4.7-94mm 6-3.5
- 1080P30/25(YUY2)、720P30/25(YUY2)、800×600、640×480
- VISCA, PELCO-D, UVC
- Tilt movement: +90° – 45°
- Pan movement: 355°
- 12V power supply
- Lens/Dome OSD
- RS232C, RS485, USB
- N.Weight: 2.16 kgs
- G.Weight: 2.75 kgs
- L 145 mm x W 148 mm x H 161 mm
- Desk top, tripod, wall, ceiling mount
TECHNICAL SPECIFICATIONS
Dementions
- Single box: L 310 mm x W 240 mm x H 230 mm
- Carton: L 500 mm x W 320 mm x H 260 mm
- 2 boxes in 1 carton
PACKAGE CONTENTS
Packing list:
- HD920-U30-K5 camera x 1
- Remote control (without battery) x 1
- USB 3.0 cable x 1
- User’s manual x 1
- Power supply x 1
- Bracket x 1
- Screws set x 1
- Certificate x 1, warranty x 1
